AWS - La Guida Completa: Dalla Teoria alla Pratica

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

{
  "family": "sample-app",
  "taskRoleArn": "arn:aws:iam::123456789012:role/ecsTaskRole",
  "executionRoleArn": "arn:aws:iam::123456789012:role/ecsTaskExecutionRole",
  "networkMode": "awsvpc",
  "requiresCompatibilities": ["FARGATE"],
  "cpu": "256",
  "memory": "512",
  "containerDefinitions": [
    {
      "name": "sample-app",
      "image": "httpd:2.4",
      "portMappings": [
        {
          "containerPort": 80,
          "protocol": "tcp"
        }
      ],
      "essential": true,
      "logConfiguration": {
        "logDriver": "awslogs",
        "options": {
          "awslogs-group": "/ecs/sample-app",
          "awslogs-region": "us-east-1",
          "awslogs-stream-prefix": "ecs"
        }
      }
    }
  ]
}

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

# Creare cluster EKS con eksctl
eksctl create cluster \
  --name my-cluster \
  --version 1.27 \
  --region us-east-1 \
  --nodegroup-name standard-workers \
  --node-type t3.medium \
  --nodes 3 \
  --nodes-min 1 \
  --nodes-max 4

# Deploy applicazione
kubectl apply -f - <<EOF
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx:1.21
        ports:
        - containerPort: 80
EOF

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36

# Lambda function per processing S3 eventi
import json
import boto3
from urllib.parse import unquote_plus

s3_client = boto3.client('s3')

def lambda_handler(event, context):
    """Process S3 upload events"""

    for record in event['Records']:
        bucket = record['s3']['bucket']['name']
        key = unquote_plus(record['s3']['object']['key'])

        print(f"Processing file: {key} in bucket: {bucket}")

        # Download file
        download_path = f'/tmp/{key}'
        s3_client.download_file(bucket, key, download_path)

        # Process file (example: image resize, data validation, etc.)
        processed_result = process_file(download_path)

        # Upload processed file
        output_key = f"processed/{key}"
        s3_client.upload_file(processed_result, bucket, output_key)

    return {
        'statusCode': 200,
        'body': json.dumps('Successfully processed files')
    }

def process_file(file_path):
    """Your processing logic here"""
    # Image processing, data transformation, etc.
    return file_path  # Return path to processed file

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41

# SAM template per API Gateway + Lambda
AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31

Resources:
  MyApi:
    Type: AWS::Serverless::Api
    Properties:
      StageName: prod
      Cors:
        AllowMethods: "'GET,POST,PUT,DELETE'"
        AllowHeaders: "'Content-Type,X-Amz-Date,Authorization'"
        AllowOrigin: "'*'"

  GetUserFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: src/
      Handler: users.get_user
      Runtime: python3.9
      Events:
        GetUser:
          Type: Api
          Properties:
            RestApiId: !Ref MyApi
            Path: /users/{id}
            Method: get

  CreateUserFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: src/
      Handler: users.create_user
      Runtime: python3.9
      Events:
        CreateUser:
          Type: Api
          Properties:
            RestApiId: !Ref MyApi
            Path: /users
            Method: post

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58

{
  "Comment": "E-commerce order processing workflow",
  "StartAt": "ValidateOrder",
  "States": {
    "ValidateOrder": {
      "Type": "Task",
      "Resource": "arn:aws:lambda:us-east-1:123456789012:function:ValidateOrder",
      "Next": "CheckInventory",
      "Catch": [
        {
          "ErrorEquals": ["ValidationError"],
          "Next": "OrderValidationFailed"
        }
      ]
    },
    "CheckInventory": {
      "Type": "Task",
      "Resource": "arn:aws:lambda:us-east-1:123456789012:function:CheckInventory",
      "Next": "ProcessPayment",
      "Catch": [
        {
          "ErrorEquals": ["OutOfStockError"],
          "Next": "NotifyOutOfStock"
        }
      ]
    },
    "ProcessPayment": {
      "Type": "Task",
      "Resource": "arn:aws:lambda:us-east-1:123456789012:function:ProcessPayment",
      "Next": "FulfillOrder",
      "Catch": [
        {
          "ErrorEquals": ["PaymentError"],
          "Next": "PaymentFailed"
        }
      ]
    },
    "FulfillOrder": {
      "Type": "Task",
      "Resource": "arn:aws:lambda:us-east-1:123456789012:function:FulfillOrder",
      "End": true
    },
    "OrderValidationFailed": {
      "Type": "Fail",
      "Cause": "Order validation failed"
    },
    "NotifyOutOfStock": {
      "Type": "Task",
      "Resource": "arn:aws:lambda:us-east-1:123456789012:function:NotifyOutOfStock",
      "End": true
    },
    "PaymentFailed": {
      "Type": "Task",
      "Resource": "arn:aws:lambda:us-east-1:123456789012:function:HandlePaymentFailure",
      "End": true
    }
  }
}

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206

AWSTemplateFormatVersion: '2010-09-09'
Description: 'Complete web application stack with VPC, ALB, EC2, RDS'

Parameters:
  EnvironmentName:
    Description: Environment name prefix
    Type: String
    Default: Production

  InstanceType:
    Description: EC2 instance type
    Type: String
    Default: t3.micro
    AllowedValues: [t3.micro, t3.small, t3.medium]

Resources:
  # VPC and Networking
  VPC:
    Type: AWS::EC2::VPC
    Properties:
      CidrBlock: 10.0.0.0/16
      EnableDnsHostnames: true
      EnableDnsSupport: true
      Tags:
        - Key: Name
          Value: !Sub ${EnvironmentName}-VPC

  InternetGateway:
    Type: AWS::EC2::InternetGateway
    Properties:
      Tags:
        - Key: Name
          Value: !Sub ${EnvironmentName}-IGW

  InternetGatewayAttachment:
    Type: AWS::EC2::VPCGatewayAttachment
    Properties:
      InternetGatewayId: !Ref InternetGateway
      VpcId: !Ref VPC

  PublicSubnet1:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC
      AvailabilityZone: !Select [0, !GetAZs '']
      CidrBlock: 10.0.1.0/24
      MapPublicIpOnLaunch: true
      Tags:
        - Key: Name
          Value: !Sub ${EnvironmentName}-Public-Subnet-AZ1

  PublicSubnet2:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC
      AvailabilityZone: !Select [1, !GetAZs '']
      CidrBlock: 10.0.2.0/24
      MapPublicIpOnLaunch: true
      Tags:
        - Key: Name
          Value: !Sub ${EnvironmentName}-Public-Subnet-AZ2

  PrivateSubnet1:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC
      AvailabilityZone: !Select [0, !GetAZs '']
      CidrBlock: 10.0.3.0/24
      Tags:
        - Key: Name
          Value: !Sub ${EnvironmentName}-Private-Subnet-AZ1

  PrivateSubnet2:
    Type: AWS::EC2::Subnet
    Properties:
      VpcId: !Ref VPC
      AvailabilityZone: !Select [1, !GetAZs '']
      CidrBlock: 10.0.4.0/24
      Tags:
        - Key: Name
          Value: !Sub ${EnvironmentName}-Private-Subnet-AZ2

  # Security Groups
  WebServerSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Security group for web servers
      VpcId: !Ref VPC
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: 80
          ToPort: 80
          SourceSecurityGroupId: !Ref ALBSecurityGroup
        - IpProtocol: tcp
          FromPort: 22
          ToPort: 22
          CidrIp: 10.0.0.0/16

  ALBSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Security group for Application Load Balancer
      VpcId: !Ref VPC
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: 80
          ToPort: 80
          CidrIp: 0.0.0.0/0
        - IpProtocol: tcp
          FromPort: 443
          ToPort: 443
          CidrIp: 0.0.0.0/0

  DatabaseSecurityGroup:
    Type: AWS::EC2::SecurityGroup
    Properties:
      GroupDescription: Security group for RDS database
      VpcId: !Ref VPC
      SecurityGroupIngress:
        - IpProtocol: tcp
          FromPort: 3306
          ToPort: 3306
          SourceSecurityGroupId: !Ref WebServerSecurityGroup

  # Application Load Balancer
  ApplicationLoadBalancer:
    Type: AWS::ElasticLoadBalancingV2::LoadBalancer
    Properties:
      Scheme: internet-facing
      SecurityGroups:
        - !Ref ALBSecurityGroup
      Subnets:
        - !Ref PublicSubnet1
        - !Ref PublicSubnet2
      Type: application

  # Auto Scaling Group
  LaunchTemplate:
    Type: AWS::EC2::LaunchTemplate
    Properties:
      LaunchTemplateName: !Sub ${EnvironmentName}-LaunchTemplate
      LaunchTemplateData:
        ImageId: ami-0c55b159cbfafe1d0  # Amazon Linux 2
        InstanceType: !Ref InstanceType
        SecurityGroupIds:
          - !Ref WebServerSecurityGroup
        UserData:
          Fn::Base64: !Sub |
            #!/bin/bash
            yum update -y
            yum install -y httpd
            systemctl start httpd
            systemctl enable httpd
            echo "<h1>Hello from ${EnvironmentName}!</h1>" > /var/www/html/index.html

  AutoScalingGroup:
    Type: AWS::AutoScaling::AutoScalingGroup
    Properties:
      VPCZoneIdentifier:
        - !Ref PrivateSubnet1
        - !Ref PrivateSubnet2
      LaunchTemplate:
        LaunchTemplateId: !Ref LaunchTemplate
        Version: !GetAtt LaunchTemplate.LatestVersionNumber
      MinSize: 1
      MaxSize: 6
      DesiredCapacity: 2
      TargetGroupARNs:
        - !Ref TargetGroup

  # RDS Database
  DBSubnetGroup:
    Type: AWS::RDS::DBSubnetGroup
    Properties:
      DBSubnetGroupDescription: Subnet group for RDS database
      SubnetIds:
        - !Ref PrivateSubnet1
        - !Ref PrivateSubnet2

  Database:
    Type: AWS::RDS::DBInstance
    Properties:
      DBInstanceIdentifier: !Sub ${EnvironmentName}-database
      DBInstanceClass: db.t3.micro
      Engine: mysql
      MasterUsername: admin
      MasterUserPassword: !Ref DatabasePassword
      AllocatedStorage: 20
      VPCSecurityGroups:
        - !Ref DatabaseSecurityGroup
      DBSubnetGroupName: !Ref DBSubnetGroup
      MultiAZ: false
      PubliclyAccessible: false

Outputs:
  LoadBalancerDNS:
    Description: DNS name of the load balancer
    Value: !GetAtt ApplicationLoadBalancer.DNSName
    Export:
      Name: !Sub ${EnvironmentName}-ALB-DNS

  DatabaseEndpoint:
    Description: RDS instance endpoint
    Value: !GetAtt Database.Endpoint.Address
    Export:
      Name: !Sub ${EnvironmentName}-DB-Endpoint

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70

from aws_cdk import (
    aws_ec2 as ec2,
    aws_ecs as ecs,
    aws_ecs_patterns as ecs_patterns,
    aws_rds as rds,
    core
)

class WebAppStack(core.Stack):
    def __init__(self, scope: core.Construct, construct_id: str, **kwargs) -> None:
        super().__init__(scope, construct_id, **kwargs)

        # VPC
        vpc = ec2.Vpc(
            self, "WebAppVPC",
            max_azs=2,
            nat_gateways=1
        )

        # ECS Cluster
        cluster = ecs.Cluster(
            self, "WebAppCluster",
            vpc=vpc
        )

        # Fargate Service with ALB
        fargate_service = ecs_patterns.ApplicationLoadBalancedFargateService(
            self, "WebAppService",
            cluster=cluster,
            memory_limit_mib=512,
            cpu=256,
            task_image_options=ecs_patterns.ApplicationLoadBalancedTaskImageOptions(
                image=ecs.ContainerImage.from_registry("nginx:latest"),
                container_port=80
            ),
            desired_count=2,
            public_load_balancer=True
        )

        # RDS Database
        database = rds.DatabaseInstance(
            self, "WebAppDB",
            engine=rds.DatabaseInstanceEngine.mysql(
                version=rds.MysqlEngineVersion.VER_8_0_28
            ),
            instance_type=ec2.InstanceType.of(
                ec2.InstanceClass.T3,
                ec2.InstanceSize.MICRO
            ),
            vpc=vpc,
            multi_az=False,
            allocated_storage=20,
            deletion_protection=False
        )

        # Allow connections from Fargate to RDS
        database.connections.allow_from(
            fargate_service.service,
            ec2.Port.tcp(3306)
        )

        # Output the load balancer URL
        core.CfnOutput(
            self, "LoadBalancerDNS",
            value=fargate_service.load_balancer.load_balancer_dns_name
        )

app = core.App()
WebAppStack(app, "WebAppStack")
app.synth()

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97

# CodePipeline per deploy applicazione Node.js
Resources:
  CodePipeline:
    Type: AWS::CodePipeline::Pipeline
    Properties:
      RoleArn: !GetAtt CodePipelineRole.Arn
      ArtifactStore:
        Type: S3
        Location: !Ref ArtifactBucket
      Stages:
        - Name: Source
          Actions:
            - Name: SourceAction
              ActionTypeId:
                Category: Source
                Owner: ThirdParty
                Provider: GitHub
                Version: '1'
              Configuration:
                Owner: myusername
                Repo: my-node-app
                Branch: main
                OAuthToken: !Ref GitHubToken
              OutputArtifacts:
                - Name: SourceOutput

        - Name: Build
          Actions:
            - Name: BuildAction
              ActionTypeId:
                Category: Build
                Owner: AWS
                Provider: CodeBuild
                Version: '1'
              Configuration:
                ProjectName: !Ref CodeBuildProject
              InputArtifacts:
                - Name: SourceOutput
              OutputArtifacts:
                - Name: BuildOutput

        - Name: Deploy
          Actions:
            - Name: DeployAction
              ActionTypeId:
                Category: Deploy
                Owner: AWS
                Provider: ECS
                Version: '1'
              Configuration:
                ClusterName: !Ref ECSCluster
                ServiceName: !Ref ECSService
                FileName: imagedefinitions.json
              InputArtifacts:
                - Name: BuildOutput

  CodeBuildProject:
    Type: AWS::CodeBuild::Project
    Properties:
      ServiceRole: !GetAtt CodeBuildRole.Arn
      Artifacts:
        Type: CODEPIPELINE
      Environment:
        Type: LINUX_CONTAINER
        ComputeType: BUILD_GENERAL1_SMALL
        Image: aws/codebuild/amazonlinux2-x86_64-standard:3.0
        EnvironmentVariables:
          - Name: AWS_DEFAULT_REGION
            Value: !Ref AWS::Region
          - Name: AWS_ACCOUNT_ID
            Value: !Ref AWS::AccountId
          - Name: IMAGE_REPO_NAME
            Value: !Ref ECRRepository
      Source:
        Type: CODEPIPELINE
        BuildSpec: |
          version: 0.2
          phases:
            pre_build:
              commands:
                - echo Logging in to Amazon ECR...
                - aws ecr get-login-password --region $AWS_DEFAULT_REGION | docker login --username AWS --password-stdin $AWS_ACCOUNT_ID.dkr.ecr.$AWS_DEFAULT_REGION.amazonaws.com
            build:
              commands:
                - echo Build started on `date`
                - echo Building the Docker image...
                - docker build -t $IMAGE_REPO_NAME:$IMAGE_TAG .
                - docker tag $IMAGE_REPO_NAME:$IMAGE_TAG $AWS_ACCOUNT_ID.dkr.ecr.$AWS_DEFAULT_REGION.amazonaws.com/$IMAGE_REPO_NAME:$IMAGE_TAG
            post_build:
              commands:
                - echo Build completed on `date`
                - echo Pushing the Docker image...
                - docker push $AWS_ACCOUNT_ID.dkr.ecr.$AWS_DEFAULT_REGION.amazonaws.com/$IMAGE_REPO_NAME:$IMAGE_TAG
                - printf '[{"name":"web","imageUri":"%s"}]' $AWS_ACCOUNT_ID.dkr.ecr.$AWS_DEFAULT_REGION.amazonaws.com/$IMAGE_REPO_NAME:$IMAGE_TAG > imagedefinitions.json
          artifacts:
            files:
              - imagedefinitions.json

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45

# Setup repository CodeCommit
aws codecommit create-repository --repository-name my-app
git clone https://git-codecommit.us-east-1.amazonaws.com/v1/repos/my-app

# buildspec.yml per CodeBuild
cat > buildspec.yml << EOF
version: 0.2
phases:
  install:
    runtime-versions:
      nodejs: 16
  pre_build:
    commands:
      - npm install
      - npm run test
  build:
    commands:
      - npm run build
  post_build:
    commands:
      - echo Build completed
artifacts:
  files:
    - '**/*'
  name: myapp-build-artifact
EOF

# appspec.yml per CodeDeploy
cat > appspec.yml << EOF
version: 0.0
os: linux
files:
  - source: /
    destination: /var/www/html
hooks:
  BeforeInstall:
    - location: scripts/install_dependencies.sh
      timeout: 300
  ApplicationStart:
    - location: scripts/start_server.sh
      timeout: 300
  ApplicationStop:
    - location: scripts/stop_server.sh
      timeout: 300
EOF

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36

# Enable GuardDuty via AWS SDK
import boto3

guardduty = boto3.client('guardduty')

# Create detector
detector_response = guardduty.create_detector(
    Enable=True,
    FindingPublishingFrequency='FIFTEEN_MINUTES'
)

detector_id = detector_response['DetectorId']

# Configure threat intelligence feeds
guardduty.create_threat_intel_set(
    DetectorId=detector_id,
    Name='CustomThreatIntel',
    Format='TXT',
    Location='s3://my-threat-intel-bucket/threats.txt',
    Activate=True
)

# Setup SNS notification for findings
guardduty.create_filter(
    DetectorId=detector_id,
    Name='HighSeverityFindings',
    Action='ARCHIVE',
    Description='Filter for high severity findings',
    FindingCriteria={
        'Criterion': {
            'severity': {
                'Gte': 7.0
            }
        }
    }
)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37

import boto3
from datetime import datetime, timedelta

ce = boto3.client('ce')

# Get cost and usage data
end_date = datetime.now().strftime('%Y-%m-%d')
start_date = (datetime.now() - timedelta(days=30)).strftime('%Y-%m-%d')

response = ce.get_cost_and_usage(
    TimePeriod={
        'Start': start_date,
        'End': end_date
    },
    Granularity='DAILY',
    Metrics=['BlendedCost'],
    GroupBy=[
        {
            'Type': 'DIMENSION',
            'Key': 'SERVICE'
        }
    ]
)

# Analyze top services by cost
services_cost = {}
for result in response['ResultsByTime']:
    for group in result['Groups']:
        service = group['Keys'][0]
        cost = float(group['Metrics']['BlendedCost']['Amount'])
        services_cost[service] = services_cost.get(service, 0) + cost

# Print top 10 services by cost
sorted_services = sorted(services_cost.items(), key=lambda x: x[1], reverse=True)
print("Top 10 Services by Cost:")
for service, cost in sorted_services[:10]:
    print(f"{service}: ${cost:.2f}")

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112

# SAM Template per E-commerce
AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31

Globals:
  Function:
    Runtime: python3.9
    Environment:
      Variables:
        PRODUCTS_TABLE: !Ref ProductsTable
        ORDERS_TABLE: !Ref OrdersTable

Resources:
  # API Gateway
  EcommerceApi:
    Type: AWS::Serverless::Api
    Properties:
      StageName: prod
      Cors:
        AllowMethods: "'*'"
        AllowHeaders: "'*'"
        AllowOrigin: "'*'"

  # DynamoDB Tables
  ProductsTable:
    Type: AWS::DynamoDB::Table
    Properties:
      BillingMode: PAY_PER_REQUEST
      AttributeDefinitions:
        - AttributeName: productId
          AttributeType: S
      KeySchema:
        - AttributeName: productId
          KeyType: HASH

  OrdersTable:
    Type: AWS::DynamoDB::Table
    Properties:
      BillingMode: PAY_PER_REQUEST
      AttributeDefinitions:
        - AttributeName: orderId
          AttributeType: S
        - AttributeName: userId
          AttributeType: S
      KeySchema:
        - AttributeName: orderId
          KeyType: HASH
      GlobalSecondaryIndexes:
        - IndexName: UserIndex
          KeySchema:
            - AttributeName: userId
              KeyType: HASH
          Projection:
            ProjectionType: ALL

  # Lambda Functions
  GetProductsFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: functions/
      Handler: products.get_products
      Events:
        GetProducts:
          Type: Api
          Properties:
            RestApiId: !Ref EcommerceApi
            Path: /products
            Method: get
      Policies:
        - DynamoDBReadPolicy:
            TableName: !Ref ProductsTable

  CreateOrderFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: functions/
      Handler: orders.create_order
      Events:
        CreateOrder:
          Type: Api
          Properties:
            RestApiId: !Ref EcommerceApi
            Path: /orders
            Method: post
      Policies:
        - DynamoDBCrudPolicy:
            TableName: !Ref OrdersTable
        - DynamoDBReadPolicy:
            TableName: !Ref ProductsTable

  ProcessOrderFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: functions/
      Handler: orders.process_order
      Events:
        ProcessOrder:
          Type: DynamoDB
          Properties:
            Stream: !GetAtt OrdersTable.StreamArn
            StartingPosition: LATEST
      Policies:
        - SNSPublishMessagePolicy:
            TopicName: !GetAtt OrderNotifications.TopicName

  # SNS Topic for notifications
  OrderNotifications:
    Type: AWS::SNS::Topic
    Properties:
      Subscription:
        - Endpoint: admin@example.com
          Protocol: email

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69

# Lambda function per processing data pipeline
import json
import boto3
import pandas as pd
from io import StringIO

s3 = boto3.client('s3')
athena = boto3.client('athena')

def lambda_handler(event, context):
    """
    Process CSV files uploaded to S3, clean data, and prepare for Athena queries
    """

    bucket = event['Records'][0]['s3']['bucket']['name']
    key = event['Records'][0]['s3']['object']['key']

    # Download CSV file
    obj = s3.get_object(Bucket=bucket, Key=key)
    df = pd.read_csv(obj['Body'])

    # Data cleaning and transformation
    df_clean = clean_data(df)

    # Convert to parquet for better performance
    parquet_buffer = StringIO()
    df_clean.to_parquet(parquet_buffer, index=False)

    # Upload processed data
    processed_key = key.replace('.csv', '.parquet').replace('raw/', 'processed/')
    s3.put_object(
        Bucket=bucket,
        Key=processed_key,
        Body=parquet_buffer.getvalue()
    )

    # Trigger Athena table refresh
    refresh_athena_table(bucket, processed_key)

    return {
        'statusCode': 200,
        'body': json.dumps(f'Successfully processed {key}')
    }

def clean_data(df):
    """Data cleaning logic"""
    # Remove duplicates
    df = df.drop_duplicates()

    # Fill missing values
    df = df.fillna(method='ffill')

    # Standardize column names
    df.columns = [col.lower().replace(' ', '_') for col in df.columns]

    return df

def refresh_athena_table(bucket, key):
    """Update Athena table metadata"""
    query = f"""
    MSCK REPAIR TABLE sales_data
    """

    athena.start_query_execution(
        QueryString=query,
        ResultConfiguration={
            'OutputLocation': f's3://{bucket}/athena-results/'
        }
    )

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

#!/bin/bash
# Deploy script per applicazione multi-tier

# 1. Deploy VPC e Networking
aws cloudformation deploy \
  --template-file infrastructure/vpc.yaml \
  --stack-name webapp-vpc \
  --parameter-overrides EnvironmentName=Production

# 2. Deploy Database Layer
aws cloudformation deploy \
  --template-file infrastructure/database.yaml \
  --stack-name webapp-db \
  --parameter-overrides \
    VpcStackName=webapp-vpc \
    DBPassword=$DB_PASSWORD

# 3. Deploy Application Layer
aws cloudformation deploy \
  --template-file infrastructure/application.yaml \
  --stack-name webapp-app \
  --parameter-overrides \
    VpcStackName=webapp-vpc \
    DatabaseStackName=webapp-db \
    KeyName=$EC2_KEY_PAIR

# 4. Deploy CDN e DNS
aws cloudformation deploy \
  --template-file infrastructure/cdn.yaml \
  --stack-name webapp-cdn \
  --parameter-overrides \
    ApplicationStackName=webapp-app \
    DomainName=$DOMAIN_NAME \
    CertificateArn=$SSL_CERTIFICATE_ARN

echo "Deployment completed. Application available at:"
aws cloudformation describe-stacks \
  --stack-name webapp-cdn \
  --query 'Stacks[0].Outputs[?OutputKey==`DistributionDomainName`].OutputValue' \
  --output text
